10HP 7.5KW 3 Cylinder 1 Single Stage Cast Iron Air Compressor Pump 31.7SCFM
This page is affiliate-supported. Prices and availability can change after the last marketplace refresh.
About this product
This unbranded 10 HP (7.5 KW) 3-cylinder, single-stage cast iron air compressor pump is designed for high-volume air delivery, achieving 31.7 SCFM flow rate and a maximum working pressure of 175 PSI. Weighing 33 kg, it is a robust and portable unit made from cast iron, emphasizing durability and a long service life. Operating on 110V, it's suitable for various pneumatic applications and comes with a three-year warranty.
Our take
This 10 HP cast iron air compressor pump seems like a serious piece of equipment for someone building or upgrading a high-performance air system. The 31.7 SCFM flow rate and 175 PSI maximum pressure are impressive, indicating it can handle demanding pneumatic tools. I like that it's constructed from cast iron for durability and has a three-year warranty, which provides good peace of mind. While it's listed as portable, at 33 kg (over 70 lbs) it's more 'portable for installation' than 'carry around'. It's a powerful pump, but remember, this is just the pump head, so a tank and motor will be needed if not replacing an existing one.
Pros & Cons
Pros
- Powerful 10 HP (7.5 KW) motor
- High 31.7 SCFM flow rate
- Maximum 175 PSI working pressure
- Durable cast iron material
- Includes a three-year warranty
Cons
- Heavy at 33 kg for portability
- Only the pump head, requires other components
Specifications
- Features Fast shipping, Long Service Life
- Warranty Three Years
- Country of Origin Unknown
- Color Blue
- Type Pancake Air Compressor
- Brand Unbranded
Show all 25 specifications
- Material
- Cast Iron
- Voltage
- 110 V
- Power Source
- Pneumatic
- Model
- W-0.9/12.5
- Net Weight
- 33 kg
- Package Size
- 56 * 36 * 45 cm
- Power
- 7.5 KW
- Set Includes
- Air Compressor Pump Head
- Flow Rate
- 31.7CFM
- Tank Material
- Steel
- Horse Power
- 10 hp
- Maximum Working Pressure
- 175 Psi
- Portability
- Portable
- Driving Mode
- Pneumatic
- Installation Hole Distance
- 252 * 170 mm
- Compression Level
- Secondary Compression
- Cylinder Diameter
- 90 * 2 + 65 * 1 mm
- Pipe Interface
- M33*1.5 mm
- Main Wheel
- 350 mm
